Threading Taps
IMC Threading taps are specially designed tools used to cut the female portion of a mating pair of metal fasteners. A Threading Tap removes material from a pre-drilled or punched hole. The result pr ...
VIEW MORELanco Type Threading Die Head
Industrial Machinery Corporation entered into the business of industrial machine manufacturing in the year 2001 and since then has been engaged in designing, manufacturing, and exporting a wide variety of industrial machines as well as accessories. Today, after around ten years of being in business, and continuously manufacturing only the best quality industrial machines, we are reckoned as one of the foremost and prime companies engaged in this business. All our machines and spare parts of our machines are made under extreme supervision by highly experienced technicians who work in our Ludhiana-based manufacturing unit. This unit is perhaps the most advanced and updated unit for industrial machinery manufacturing. We have adeptness in designing and manufacturing a wide range of industrial machines and their spare parts. Lanco-type die head is a part of that wide range. A Lanco-type die head is a machine that we have been manufacturing since our formation and is made will all the expertise and experience we have in this business. The Lanco type died head manufactured by us is hugely popular in the market it has all the qualities which have the quality to attract all the buyers of the market.
VIEW SPECIFICATIONSTags
Lanco Type Threading Die Head, bolt threading die head, lanco type threading die head, pipe threading die head, rebar threading die head, rod threading die head, threading die headAvailable Options
Specifications
Industrial Machinery Corporation entered into the business of industrial machine manufacturing in the year 2001 and since then has been engaged in designing, manufacturing, and exporting a wide variety of industrial machines as well as accessories. Today, after around ten years of being in business, and continuously manufacturing only the best quality industrial machines, we are reckoned as one of the foremost and prime companies engaged in this business. All our machines and spare parts of our machines are made under extreme supervision by highly experienced technicians who work in our Ludhiana-based manufacturing unit. This unit is perhaps the most advanced and updated unit for industrial machinery manufacturing. We have adeptness in designing and manufacturing a wide range of industrial machines and their spare parts. Lanco-type die head is a part of that wide range. A Lanco-type die head is a machine that we have been manufacturing since our formation and is made will all the expertise and experience we have in this business. The Lanco type died head manufactured by us is hugely popular in the market it has all the qualities which have the quality to attract all the buyers of the market.
We make our lanco type die head using finest grade steel as raw material which is bought from the most reliable and experienced suppliers who guarantee only the best quality raw material to us. Prior to use, this raw material is comprehensively checked by our quality supervision team who makes sure that all the raw material is free from all kinds of flaws and defects. Upon the satisfaction of this team, the raw material is forwarded for use. Our production unit based in Ludhiana is one of the most advanced manufacturing units comprising of vast ground for machines manufacturing and maintenance, the best and most advanced machines, the latest technologies, and vastly experienced technician who are always in an endeavor to build only the best Lanco Type Die Head. The Lanco type die head is available in an assortment of types with us such as pipe threading die head, bar threading die head, bolt threading die head, and rebar threading die head.
- Lanco Type Die Head machines are revolving tools designed for hand-operated, semi-automatic, and automatic threading machines
- Wide range coverage for threading diameters 1/4" to 9-1/4" (6 to 235mm)
- Lanco Type Die Head machines are available for standard, heavy-duty, and large diameter applications and will thread up to and including Class 3 tolerances
- Lanco Heads are for producing straight threads and "jam cutting" shorter length taper threads like NPT and BSTP
- Seven sizes to thread from 1/4" to 6", 6 to 152 mm, and 1/8" to 6" nominal pipe. Oversize capacities available
- CRX Lanco Type Die Head machines are used to generate straight threads of relatively fine pitch and a short length on large diameters
- Incorporates six chasers with a range of 1-7/8" to 9-1/4" maximum oversize range
|
Lanco Type Die Head Capacity 2.1/2" to 6" 4" to 8" |
| Die Head Size | Holder Set/Sets (Provided) | Chaser Section |
| 1/4" to 1" Capacity Die Head | 1/4" to 1" | 3" x 1.3/64 (Set of 4 Pcs) |
| 3/8" to 1. 1/2" Capacity Die Head | 3/8" to 1. 1/2" | 4" x 1.3/64 (Set of 4 Pcs) |
| 1/2" to 2.1/2" Capacity Die Head | 1/2" to 1. 1/2" 1.5/8 to 2.1/2" | 4" x 1.1/4"(Set of 4 Pcs) |
| 1" to 4" Capacity Die Head | 1" to 2" 2.1/2" to 4" | 4" x 1.1/4" (Set of 4 Pcs) 5" x 2.1/4" (Set of 4 Pcs) |
| 2.1/2" to 6" Capacity Die Head | 2.1/2" to 3" 3.1/2" to 4" 4.1/2" to 6" | 5" x 2.1/4"(Set of 6 Pcs) |
| 4" to 8" Capacity Die Head | 4" to 5.1/2" 5.1/2" to 8" | 5" x 2.1/4" (Set of 6 Pcs) |
Tangential Chaser
IMC Tangential Chasers are manufactured from imported High Speed Steel which must pass exacting metallurgical standard. Experienced heat treatment with the automatic imported heat treatment plant and imported Testing equipments, assures that they will perform satisfactorily in service and produce quality threads within the tolerance for which they ware intended.
IMC Chaser are interchangeable. If one Pc. Of a chaser set is damaged & is beyond use. Then same No. pc. Of the other chaser set lying in stock may be used and there will not be any difference in threading performance and the damaged set can be replaced without the necessity of replacing entire set.
