Specifications

For many years, we have been designing and manufacturing a wide range of industrial machines and what’s better is that our machines have gained a huge popularity not only in national market but international market as well. The main reason behind this huge success of our machines is that in all the ten years of being in business, we have sustained the quality of our machines as it was ten years back. Through all the gained experience and expertise, we have gained proficiency in designing and developing a wide range of industrial machines and spare parts. One such part that is used widely by industries, factories and tool-rooms is the bolt threading tangential chase which is made all the latest technologies, technical know-how and acquired skills. The bolt threading tangential chaser made by is capable of getting adjusted with a wide range of machines and thus are used in variety of industrial tasks like  cutting external threads on equipments like big bolts, fasteners and pipes. Following is the list of types of threading tangential chaser that we are capable of building at our manufacturing unit based in Ludhiana:

• Thread cutting Tangential chaser

• Pipe threading Tangential chaser

• Bolt threading Tangential chaser

• Rod threading Tangential chaser ? ?

Our threading tangential chaser is best suited for Landis, Lanco, Landmatic, Gents and Wagner type die heads. The Bolt Threading Tangential Chaser that we make here at our Ludhiana unit are made for all threading standards and die head sections in 4 and 6 pieces. This threading tangential chaser is built at our Ludhiana based manufacturing unit using the finest quality steel as raw material which is HSS M2 steel. And it is because of this reason only that we are using best quality raw material in the manufacturing process our bolt threading tangential chaser is acknowledged across the world market for accurate and to-the-point precision of thread profiling. Our bolt threading tangential chaser is a perfect make for all thread standards like METRICS [Pitch 0.5mm-5.0mm], UNIFIEDS [8tpi-40tpi], and IMPERIALS [5tpi-40tpi] Chasers to thread special profiles and ACME type threads are also made as per requirement. The entire bolt threading tangential chaser, that we build here are used in cutting a wide variety of threads. Some of these thread types are mentioned below with extreme capacity, accuracy and quality:

• BSP

• BSPT

• NPT

• UNF

• UNC

• BSW

Listed below are some of the extra-ordinary features that we infuse in the entire bolt threading tangential chaser manufactured by us at Industrial Machine Corporation manufacturing unit based in Ludhiana:

• Manufactured from imported High-speed steel.

• Uniform heat treatment for required hardness

• High tensile strength ensures longer life.

• Superb durability

• Provides efficient performance on every occasion

• Has a perfect dimensional accuracy

• Low maintenance threading tangential chasers

• Cost-effectiveness is another attribute of our threading tangential chasers

• Our machines are well designed

• Provides reliable performance every time

• World class quality

• Longer life

Let’s have an epigrammatic look towards the technical features of the bolt threading tangential chaser manufactured by us in Ludhiana:

• Maximum Pitch Can Be Rolled-2.5 mm

• Maximum Diameter Can Be Rolled In Feed-25 mm

• Maximum Rolling Force-8 Tons

• Maximum Rolling Length In Feed-80 mm

• Spindle Diameter (Bore Diameter)-54 mm

• Power For Roll Spindles-3 H.P. 1440 RPM

• Maximum Rolling Length through Feed-Indefinite

• Maximum Diameter Can Be Through Feed-16 mm

• Maximum Outer Diameter Thread Rolls-150 mm
