Specifications

Ever since we stepped into the business of designing and developing industrial machines which was in 2001, we have been dedicatedly designing, developing and exporting all the industrial machines to our worldwide clients. All the machines that we make are best in quality, dependability, adaptability, handiness, compatibility, efficiency, effectiveness and this is probably the reason why our machines are most famous in the market. Using all experience and technical know-how, we can make a wide range of machines and accessories and one of them is circular thread rolling dies. Not only circular thread rolling dies we are technically prepared to make circular thread rolling dies which are made, advanced enough to provide best results in accurate ad precise threading jobs on various kinds of machines, fasteners, auto-parts and various other components. These Circular Thread Rolling Dies are generally made from cold work tools steel [D2 or similar] and also in high speed steel [M2]. Through the expertise and experience that we have gained in the field of industrial machine manufacturing, we are now dexterous in making three variants of Circular Thread Rolling Dies and they are:

• In feed

• Thru feed

• In feed type

Not only these three types of circular thread rolling dies, we are also capable of building specially treated and customized dies for thread rolling of those v equipments which are rather tough to roll on. Examples of such tough materials are Stainless steel and Fasteners of After Heat treatment state [AHT]. The circular thread rolling dies that we make here are made with maximum diameter of 300 M.M. and maximum width of 250 M.M. Apart from this, we also make circular thread rolling dies in a customized manner with size of bore diameter. The Circular Thread Rolling Dies made by us is perfect to create threads like Metrics [Pitch 0.8mm-6mm], Unifieds/British threads [Pitch 4 tpi-32 TPI] and other thread forms like ACME, Knuckle, and Buttress etc. Listed below is the list of features of our circular thread rolling dies that are manufactured in our industrial machine manufacturing base located in Ludhiana:

• Accuracy of the thread profile is excellent

• Tensile strength is greatly increased

• Higher quality surface finish

• Superior wear resistance

• Greater resistance to fatigue

• Increased resistance to corrosion

• Production far more efficient in terms of time and cleanliness

• Simple operation in terms of repetitious Mentioned below, are some of the valuable information that you must have prior to order your circular thread rolling dies and share with us at the time of placing an order:

• Roll’s outer diameter, bore, face width and keyway size

• Type of dies- in-feed (plunge-feed) or thru-feed

• Threading-diameter and thread pitch along thread standard of fastener to be rolled

• Quality -regular for general thread rolling and premium for stainless steel and hard material rolling.

• Angle of entry & exit- for thru feed rolls

• Any special operation- radiuses run out grinding, chamfer angles other than standard 30 deg, etc.

• Do mention the component hardness while ordering for rolls for AHT operation.
